°C
Product description
- – 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
- typically ± 0.2 K at +25 °C
- 0 - 10 V
- Cable gland
- IP65
Calibratable contact temperature measuring transducer (compact version) THERMASGARD® ALTM 1 with eight switchable measuring ranges, continuous output, in an impact-resistant plastic housing with quick-locking screws, optionally with/without display, incl. clamping strap.
The contact sensor is used to measure the temperature on cables, pipes (e.g. cold and hot water) or on heating pipes for heating control. The sensor is calibrated at the factory; fine adjustment by a specialist is possible depending on the environment.
The contact sensor is used to measure the temperature on cables, pipes (e.g. cold and hot water) or on heating pipes for heating control. The sensor is calibrated at the factory; fine adjustment by a specialist is possible depending on the environment.
Technical data
| Measuring range | Temperature |
| Power supply | 24 V AC/DC (± 10%) |
| Display | Yes |
| Protection class | IP65 |
| Output version | Cable gland |
| Measuring range | – 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C |
| Features | none |
| Output | 0 - 10 V |
