Product description
- Control range: +5...+30 °C, adjustable via setpoint potentiometer with numerical scale or +21 °C (± 8 K), adjustable via setpoint potentiometer with threshold arrow (center position/ +/ - ) / +41...+86 °F
- Proportional band: internally adjustable via potentiometer, heating +0.5...+3 K (1 K factory setting) cooling +0.5...+3 K (2 K factory setting)
- Neutral zone: internally adjustable via potentiometer, +1...+5 K (1 K factory setting)
- Control behavior: PI
- Outputs: 1 x heating, 1 x cooling, 0 - 10 V or 10 - 0 V reversible, max. 5 mA
- Potentiometer, LED displays
- Temperature sensor: internal or external (selectable via jumper) Pt 1000 to DIN EN 60751, class B
- 24 V AC/ DC (± 10 %)
- Printing: +21°C (±8K)
- IP30
Used in dry individual rooms that are heated or cooled with radiators, cooling ceilings, ventilation or air conditioning systems, or as a remote control for air conditioning units, e.g. in hotels, offices or hospitals, or as a room thermostat.
