Temperature
-
°CTHERMASREG® KTR-1
1102-3010-1100-150
- Temperature controller (external setting)
- -35 ... +35 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 3 K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
-
°CTHERMASREG® KTR-060
1102-3010-1100-350
- Temperature controller (external setting)
- 0 ... +60 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 3 K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
-
°CTHERMASREG® KTR-090
1102-3010-1100-450
- Temperature controller (external setting)
- 0 ... +90 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 3 K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
-
°CTHERMASREG® KTR-0120
1102-3010-1100-550
- Temperature controller (external setting)
- 0 ... +120 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 5 K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
-
°CTHERMASREG® KTR-50140
1102-3010-1100-650
- Temperature controller (external setting)
- +50 ... +140 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 5 K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
-
°CTHERMASREG® KTR-060 U
1102-3010-2100-350
- Temperature monitor (internal setting)
- 0 ... +60 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 3K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
-
°CTHERMASREG® KTR-090 U
1102-3010-2100-450
- Temperature monitor (internal setting)
- 0 ... +90 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
- Switching differential: 3K
- Installation length: approx. 205 mm (with flange); approx. 184 mm (without flange)
- Thermowell: made of metal, material CuZn37 (2.0321), Ø 14 mm, NL = 205 mm
- IP65
81,95 €
incl. VAT 97,34 €
We also manufacture individually
Do you have special requirements?As a manufacturer with our own production facilities in Germany, we are always in a position to produce products outside the standard range.
Contact us
