Temperature sensor active (0-10V/ 4-20mA)

With our active THERMASGARD® temperature sensors, you are always in control - whether as a room, flush-mounted, outdoor, cable or duct temperature sensor. The sensor devices are characterized by a large number of standard measuring ranges. Our patented AOS technology automatically selects the correct output signal for the sensors - depending on the connected device.

°C
Immersion-/screw-in duct temperature transmitters

THERMASGARD® TM54-U 50mm KV

1101-7171-0019-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typical ± 0.2 K at +25 °C
installation dimensions: 50 mm
0 - 10 V
cable gland
IP65
183,32 €

plus 19% VAT. + shipping

incl. VAT: 218,09 €
°C
Immersion-/screw-in duct temperature transmitters

THERMASGARD® TM54-I 50mm KV

1101-7172-0019-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typical ± 0.2 K at +25 °C
Installation length: 50 mm
4...20 mA
Cable gland
IP65
183,32 €

plus 19% VAT. + shipping

incl. VAT: 218,09 €
°C
Immersion/screw-in duct temperature transmitter

THERMASGARD® TM54-I 150mm

1101-7152-0039-910
– 20... + 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

installation depth: 150 mm

4..20 mA

pressure screw

IP54
184,61 €

plus 19% VAT. + shipping

incl. VAT: 219,57 €
°C
Immersion/Threaded/Channel Temperature Transmitter

THERMASGARD® TM54-U 150mm

1101-7151-0039-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

mounting dimensions: 150 mm

0-10V

pressure adjustment screw

IP54
184,61 €

plus 19% VAT. + shipping

incl. VAT: 219,57 €
°C
Immersion-/Screw-in duct temperature transmitters

THERMASGARD® TM54-I 200mm

1101-7152-0049-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

installation length: 200 mm

4..20 mA

pressure screw

IP54
187,13 €

plus 19% VAT. + shipping

incl. VAT: 222,66 €
°C
Immersion/screw-in channel temperature transducer/sensor

THERMASGARD® TM54-U 200mm

1101-7151-0049-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

Mounting length: 200 mm

0-10V

Locking screw

IP54
187,13 €

plus 19% VAT. + shipping

incl. VAT: 222,66 €
°C
Immersion/Threaded Duct Temperature Transmitter

THERMASGARD® TM54-U 100mm KV

1101-7171-0029-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typical ± 0.2 K at +25 °C
installation depth: 100 mm
0 - 10 V
cable gland
IP65
187,38 €

plus 19% VAT. + shipping

incl. VAT: 222,91 €
°C
Immersion / Insertion / Screw-in duct temperature transmitter

THERMASGARD® TM54-I 100mm KV

1101-7172-0029-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
Immersion length: 100 mm
4...20 mA
Cable gland
IP65
187,38 €

plus 19% VAT. + shipping

incl. VAT: 222,91 €
°C
Immersion-/ Screw-in duct temperature transducers

THERMASGARD® TM54-I 250mm

1101-7152-0059-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

Immersion lengths: 250 mm

4..20mA

Adjusting screw

IP54
189,46 €

plus 19% VAT. + shipping

incl. VAT: 225,37 €
°C
Submersible/Threaded/Duct Temperature Transmitter

THERMASGARD® TM54-U 250mm

1101-7151-0059-910
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

installation length: 250 mm

0-10V

threaded pressure screw

IP54
189,46 €

plus 19% VAT. + shipping

incl. VAT: 225,37 €
°C
Immersion-/screw-in channel temperature transducer

THERMASGARD® TM65-Modbus-T3 50mm

1101-7236-0010-000
−50...+150 °C
Mounting dimensions: 50 mm
Channel sensor
Modbus
IP65
189,83 €

plus 19% VAT. + shipping

incl. VAT: 225,74 €
°C
Immersion-/screw-in duct temperature transmitter

THERMASGARD® TM65-Modbus-T3 100mm

1101-7236-0020-000
–50...+150 °C
Mounting depth: 100 mm
Duct immersion
Modbus
IP65
190,16 €

plus 19% VAT. + shipping

incl. VAT: 226,26 €
°C
Outdoor/Wet-Room Temperature Transmitters

THERMASGARD® ATM2-Modbus-T3

1101-12C6-0000-000
−50...+150 °C
typically ±0.2 K at +25 °C
switchable metric / imperial
Modbus
IP65
190,23 €

plus 19% VAT. + shipping

incl. VAT: 226,33 €
°C
Immersion-/screw-in channel temperature transmitter

THERMASGARD® TM65-Modbus-T3 150mm

1101-7236-0030-000
50...+150 °C
Installation depth: 150 mm
Duct sensor
Modbus
IP65
190,41 €

plus 19% VAT. + shipping

incl. VAT: 226,51 €
°C
Duct immersion / screw-in channel temperature transmitter

THERMASGARD® TM65-Modbus-T3 200mm

1101-7236-0040-000
−50...+150 °C
Mounting depth: 200 mm
Channel sensor
Modbus
IP65
190,66 €

plus 19% VAT. + shipping

incl. VAT: 226,76 €
°C
Immersion/Threaded/Duct Temperature Transmitter

THERMASGARD® TM65-Modbus-T3 250mm

1101-7236-0050-000
–50...+150 °C
Mounting depth: 250 mm
Duct sensor
Modbus
IP65
191,02 €

plus 19% VAT. + shipping

incl. VAT: 227,31 €

We also manufacture individually

Do you have special requirements? As a manufacturer with our own production facilities in Germany, we are also able to produce products outside of the standard range at any time.
